ADD ON PANDA SHELVING SYSTEMS




Add on Panda Shelving Systems

The Panda Shelving Systems can be extended as required by connecting additional units of Roll Posts / Extended back panels to the existing units, side by side or back to back . The efficient design & versatility of the panda shelving system using add on units enables the systems to be designed & built to suit a diverse range of applications.


For example :

A) If you want to have 2 units back to back then you need to order a standard unit of the configuration you require and additionally for the back side order only the Roll Posts, Shelves and Kick Plate whereby you save the cost of 1 Back Panel.

B) If you want to have 2 units side by side you need to order a standard unit of the configuration you require and additionally for the side unit only order the extended Back Panel and Single Roll Post along with the shelves and Kick Plate whereby you save the cost of 1 Roll Post.

In this way, as more units are added to make a wall side by side, or an aisle having side by side and back to back shelving units, the system becomes more cost effective and a more efficient storage system.



ASURP 123

Single piece roll post 1275 x 300mm

ASURP 124

Single piece roll post 1275 x 400mm

ASURP 1245

Single piece roll post 1275 x 450mm

ASURP 125

Single piece roll post 1275 x 500mm

ASURP 126

Single piece roll post 1275 x 600mm

ASURP 183

Single piece roll post 1875 x 300mm

ASURP 184

Single piece roll post 1875 x 400mm

ASURP 1845

Single piece roll post 1875 x 450mm

ASURP 185

Single piece roll post 1875 x 500mm

ASURP 186

Single piece roll post 1875 x 600mm

ASURP 213

Single piece roll post 2175 x 300mm

ASURP 214

Single piece roll post 2175 x 400mm

ASURP 2145

Single piece roll post 2175 x 450mm

ASURP 215

Single piece roll post 2175 x 500mm

ASURP 216

Single piece roll post 2175 x 600mm

ASURP 233

Single piece roll post 2375 x 300mm

ASURP 234

Single piece roll post 2375 x 400mm

ASURP 2345

Single piece roll post 2375 x 450mm

ASURP 235

Single piece roll post 2375 x 500mm

ASURP 236

Single piece roll post 2375 x 600mm

ASUEBP 1275

2 pcs. of extended back panel 1275mm(28 sets of ASUBN to be ordered separately).

ASUEBP 1875

2 pcs. of extended back panel 1875mm
(42 sets of ASUBN to be ordered separately).

ASUEBP 2175

2 pcs. of extended back panel 2175mm
(50 sets of ASUBN to be ordered separately).

ASUEBP 2375

2 pcs. of extended back panel 2375mm
(56 sets of ASUBN to be ordered separately).

ASUBN

M6 x 10mm pan head set of one nut & bolt.
